Titanium anode for chlor-alkali industry
Production process:Sandblasting, pickling, brushing
Titanium content:99.6%
Product Name:Chlor-alkali using MMO titanium anode and titanium cathode
Other names:MMO titanium anode, DSA titanium anode, insoluble titanium anode
Substrate:Titanium Grade 1 and Grade 2
Available anode types:Mesh, sheet/plate, rod/wire, tube/pipe
Titanium Anode for Chlor-Alkali Industry: Premium MMO Coated Electrodes
When your chlor-alkali plant demands energy efficiency and long-term reliability, Titanium anode for chlor-alkali industry from Baoji City ShenAo Metal Materials delivers proven performance. Our MMO (Mixed Metal Oxide) coated anodes feature high-purity titanium substrates (Grade 1 & Grade 2, 99.6% titanium content) with precision Ru-Ir oxide coatings that maintain chlorine evolution potential below 1.13V. You'll achieve current densities exceeding 3,000-4,000 A/m² in membrane cells. With 17 years of manufacturing expertise and accelerated life testing exceeding 100 hours per HG/T 2471-2011 standards, our anodes translate to 5-8 years operational lifespan in your facility.
Why Choose Our MMO Titanium Anodes?
Your chlor-alkali operation faces constant pressure to reduce energy costs and minimize downtime. Traditional graphite anodes contaminate your electrolyte and require frequent replacement. Our product solves these challenges.
The dimensionally stable design maintains zero-gap configuration in membrane cells. This reduces voltage drops significantly. You'll see 15-20% energy efficiency improvements when retrofitting older diaphragm cells.
Our catalytic coating delivers superior chlorine selectivity. It minimizes unwanted oxygen evolution. This ensures higher chlorine gas purity for your downstream processes.
|
|
|
|
|
|
|
|
|
 |
|
|
 |
|
|
|
|
Technical Specifications
|
Parameter
|
Specification
|
|
Substrate Material
|
Titanium Grade 1, Titanium Grade 2
|
|
Titanium Content
|
99.6%
|
|
Coating Type
|
MMO (Ru-Ir-Ti Mixed Metal Oxides)
|
|
Coating Loading
|
8-20 g/m²
|
|
Chlorine Evolution Potential
|
<1.13V (vs. SCE)
|
|
Current Density Capacity
|
3,000-4,000 A/m²
|
|
Accelerated Life Test
|
>100 hours (HG/T 2471-2011)
|
|
Expected Service Life
|
5-8 years
|
|
Available Forms
|
Mesh, Sheet/Plate, Rod/Wire, Tube/Pipe
|
|
Production Process
|
Sandblasting, Pickling, Precision Brushing
|
|
Dimensional Tolerance
|
±0.1mm (for membrane cell applications)
|
Key Applications in Your Operations
Ion-Exchange Membrane Electrolysis
Your modern membrane cell electrolyzer requires anodes with precise dimensions. Our products enable zero-gap cell designs. You'll produce high-purity caustic soda (32% or 50% concentration) with minimized voltage loss.
Diaphragm Cell Retrofitting
Replace your outdated graphite anodes without complete system overhaul. You'll eliminate carbon impurities from chlorine gas. Energy consumption drops by 15-20% immediately after installation.
Sodium Hypochlorite Generation
For onsite water disinfection systems, our anodes withstand frequent polarity reversals. They perform reliably even in low-concentration brine electrolytes. Coating delamination becomes a concern of the past.
 |
 |
 |
 |
 |
 |
 |
Product production process
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Our Manufacturing Excellence
Since 2008, we've operated from China's Titanium Valley in Baoji City. Our location gives you access to superior titanium resources and advanced processing capabilities.
We use mature bimetallic explosive welding technology. Our active coating manufacturing process ensures consistent quality. Every anode undergoes rigorous multi-layer inspection before reaching your facility.
Quality Control You Can Trust
· X-ray Fluorescence (XRF) verifies noble metal content in every batch
· Scanning Electron Microscopy (SEM) confirms the essential 'cracked mud' surface pattern
· Accelerated Life Tests predict long-term stability in your specific conditions
· Specialized bending tests and thermal shock cycles validate coating adhesion
· Dimensional precision meets zero-gap membrane cell requirements within 0.1mm tolerance
Customization for Your Specific Needs
No two chlor-alkali plants operate identically. We provide customized Titanium anode for chlor-alkali industry solutions matching your:
· Cell geometry requirements (mesh, plate, rod, or tube configurations)
· Current density specifications
· Electrolyte composition and temperature ranges
· Installation and maintenance schedules
Whether you need small-batch testing samples or full-scale production volumes, we deliver on time with consistent quality.
 |
 |
 |
 |
 |
 |
 |
 |
 |
Application Industries
 |
 |
 |
 |
 |
 |
 |
 |
Our Factory
Our Patents and Honors
Our Packaging
|
|
|
|
|
|
|
|
|
|
|
|
Frequently Asked Questions
Q: How long will your titanium anodes final in my chlor-alkali plant?
A: Beneath standard working conditions, our anodes ordinarily give 5-8 a long time of nonstop benefit. Genuine life expectancy depends on your current thickness, electrolyte concentration, and working temperature. Our quickened life testing surpasses 100 hours per HG/T 2471-2011 benchmarks, giving you unsurprising performance.
Q: Can I retrofit your anodes into my existing stomach cells?
A: Completely. We've made a difference hundreds of plants move from graphite to MMO titanium anodes. You'll see quick vitality reserve funds of 15-20% and kill carbon defilement. We give custom measurements to fit your current cell setup without major modifications.
Q: What makes your coating distinctive from other suppliers?
A: Our Ru-Ir-Ti oxide blend is optimized particularly for chlor-alkali applications. The coating keeps up chlorine advancement potential underneath 1.13V whereas minimizing oxygen advancement. We confirm coating stacking (8-20 g/m²) utilizing XRF investigation and assess the surface morphology with SEM to guarantee most extreme catalytic surface area.
Q: Do you offer specialized bolster amid installation?
A: Yes. Our experienced specialized group gives establishment direction and operational suggestions. We offer assistance you optimize cell parameters to maximize anode life expectancy and vitality productivity. Post-installation bolster proceeds all through your anode's benefit life.
Q: What quality certifications do your items meet?
A: Our item complies with HG/T 2471-2011 benchmarks. Each group experiences comprehensive testing counting coating examination, surface morphology review, quickened life testing, attachment confirmation, and dimensional exactness checks.
Partner with Titanium Valley Expertise
You merit a provider who gets it the specialized requests and financial weights of chlor-alkali generation. Our 17-year track record serves hundreds of electrochemical endeavors worldwide.
We combine research-driven development with fabricating greatness. Your custom necessities get incite consideration from our committed specialized group.
Contact Us Today
Ready to improve your Titanium anode for chlor-alkali industry efficiency? Send your specific requirements to zh@baojiti.com.cn and receive a customized solution proposal within 24 hours.
