China OEM Free Sample Cheap mixed metal oxide coated titanium anodes Factory Supplier

Mixed Metal Oxide Coated Titanium Anodes - High-Performance Industrial Electrodes

Baoji City ShenAo Metal Materials Co., Ltd. delivers enterprise-grade mixed metal oxide coated titanium anodes engineered for demanding industrial applications. With 17 years of manufacturing excellence since 2008, our anodes feature superior coating thickness of 8–12 μm, metal content of 8–25 g/㎡, and proven working life exceeding 5 years. Built on high-purity titanium substrates (>99.99%) and advanced PVD coating technology, these dimensionally stable anodes operate efficiently at temperatures below 60°C, delivering consistent performance in wastewater treatment, cathodic protection, and electrochemical processes where reliability is non-negotiable.

What Are Mixed Metal Oxide Coated Titanium Anodes?

The items, commonly known as DSA (Dimensionally Steady Anodes), are specialized electrochemical cathodes. They comprise of a titanium base coated with respectable metal oxides like Ruthenium, Iridium, and Tantalum.

This coating empowers particular electrochemical responses without expending the anode itself. You get steady measurements all through the benefit life. No more fluctuating terminal holes or defilement issues.

Unlike conventional graphite or lead anodes, our products solve basic problems:

· Dimensional insecurity that increments voltage

· Heavy metal defilement of your electrolyte

· Excessive vitality consumption

· Frequent substitution costs

Technical Specifications

Parameter	Specification
Material	Titanium (>99.99% purity)
Coating Type	Mixed Metal Oxides (RuO₂, IrO₂, Ta₂O₅)
Coating Thickness	8–12 μm
Metal Content	8–25 g/㎡
Production Process	PVD Coating / Melt Technology
Working Temperature	<60°C
Current Density	Up to 2000 A/m²
Working Life	>5 years
Surface Morphology	Cracked-mud structure for maximum active area

Key Advantages You'll Appreciate

Exceptional Durability

Your operations can't afford downtime. Our anodes deliver over 5 years of continuous service, dramatically reducing replacement frequency and maintenance costs.

Superior Corrosion Resistance

Whether you're working in highly acidic (pH < 1) or alkaline environments, these anodes maintain structural integrity. The specialized coating withstands aggressive chemical attacks.

Energy Efficiency

Lower overpotential means reduced power consumption. You'll see measurable energy savings with oxygen or chlorine evolution overpotential typically below 1.15V.

Zero Contamination

The insoluble nature of mixed metal oxide coated titanium anodes ensures your end products remain pure. No heavy metal erosion products contaminate your process.

Custom Solutions

We understand your application is unique. Our team provides customized sizes, coating formulations, and specifications to match your exact requirements.

Product production process

Industrial Applications

Progressed Wastewater Treatment

Tackle hard-headed natural poisons in pharmaceutical profluent or landfill leachate. Our anodes control electrochemical oxidation frameworks that viably diminish COD and BOD levels.

Impressed Current Cathodic Assurance (ICCP)

Protect your framework ventures. These lightweight, high-current anodes anticipate erosion in seaward stages, underground pipelines, and strengthened concrete structures for 20+ years.

Non-Ferrous Metal Electrowinning

Recovering Copper, Nickel, or Cobalt? Our anodes give dimensional soundness in exceedingly acidic sulfuric corrosive electrolytes. You'll deliver high-purity metal cathodes whereas avoiding short-circuiting.

Chlor-Alkali Industry

Achieve steady chlorine and caustic pop generation with terminals outlined for nonstop chlorine advancement reactions.

Surface Treatment & Electroplating

Maintain uniform current dissemination for prevalent coating quality in enhancing and utilitarian plating operations.

Why Choose ShenAo Metal Materials?

17 A long time of Demonstrated Expertise

Since 2008, we've been found in China's Titanium Valley—Baoji, Shaanxi. Our profound industry information and fabricating capabilities guarantee you get solid products.

Mature Fabricating Technology

We utilize progressed bimetallic unstable welding and dynamic coating forms. Each anode experiences strict quality testing to meet universal standards.

Complete Benefit System

From investigate and improvement to generation and conveyance, we keep up comprehensive quality administration. Little clump testing or large-scale production—we convey on time.

Strong Industry Partnerships

Hundreds of electrochemical application ventures believe us as their long-term provider. Our notoriety talks for itself.

Customer-Centric Approach

We work closely with your specialized group to get it your particular challenges. Our arrangements are custom fitted, not one-size-fits-all.

Application Industries

Our Factory

Our Patents and Honors

Our Packaging

Frequently Asked Questions

How long do the products last?

Our anodes are engineered for over 5 years of working life under standard operating conditions (temperature <60°C). Actual lifespan depends on current density, electrolyte composition, and maintenance practices.

Can you customize the coating formulation?

Completely. We alter the proportion of Ruthenium, Iridium, and Tantalum oxides based on your particular electrochemical reactions—whether oxygen advancement, chlorine era, or other applications.

What's the most extreme current thickness these anodes can handle?

Our anodes bolster current densities up to 2000 A/m², making them appropriate for high-intensity mechanical processes.

How do these compare to graphite or lead anodes?

Unlike consumable graphite or poisonous lead anodes, our titanium-based anodes keep up steady measurements, deliver no defilement, devour less vitality, and final altogether longer.

What quality measures do you follow?

We follow to ASTM and NACE conventions all through fabricating. Each item experiences thorough testing some time recently conveyance to guarantee it meets your specialized requirements.

Do you give specialized back for installation?

Yes. Our experienced group offers direction on establishment, working parameters, and investigating to offer assistance you maximize anode execution and life expectancy.

Contact Us

Ready to upgrade your electrochemical systems with mixed metal oxide coated titanium anodes? Reach out to our team at zh@baojiti.com.cn for technical specifications and custom solutions.
