MMO-Coated Titanium Strip Anodes for Cathodic Protection and Grounding Systems

What are MMO-Coated Titanium Strip Anodes?

MMO-coated titanium strip anodes are long, flexible strip anodes made of pure titanium, coated with a mixed metal oxide (MMO) layer. This allows the anode to conduct electricity efficiently and operate stably for long periods in harsh environments.

Due to its strip structure, MMO-coated titanium strip anodes can distribute current more evenly than traditional rod or mesh anodes. They are widely used in cathodic protection systems, especially suitable for long-distance structures such as pipelines, storage tanks, and grounding grids.

Why Choose MMO-Coated Titanium Strip Anodes?

Long Service Life

The biggest advantage of MMO-coated titanium strip anodes is their service life. The stable mixed metal oxide coating provides a service life of 20-50 years, depending on operating conditions.

Unlike traditional anodes that dissolve quickly, titanium remains intact during the electrochemical reaction of the coating.

High Efficiency and Low Consumption

The MMO coating exhibits excellent catalytic performance. This means:

Lower power consumption

Stable output current

Higher current efficiency

This makes MMO-coated titanium strip anodes a cost-effective choice in the long run.

Uniform current distribution

Due to its strip shape, this anode can distribute current evenly over a large surface area. Suitable for:

Tank bottoms

Concrete structures

Long pipelines

Better current distribution = better protection.

Applications of MMO-coated titanium strip anodes

Catholic protection of underground pipelines

MMO-coated titanium strip anodes are used to protect buried pipelines.

Steel pipelines are susceptible to corrosion from soil moisture and chemicals. Installing strip anodes on the pipeline creates a protective electric field that prevents corrosion before it occurs.

Application industries:

Oil and gas pipelines

Water supply pipelines

Chemical transportation systems

Tank bottom protection systems

Tanks, especially oil tanks, often experience corrosion at the bottom due to moisture buildup.

MMO-coated titanium strip anodes are installed below the tank bottom (usually in sand or concrete) to form a uniform protective layer.

Advantages:

Full-area coverage

No blind spots

Long-term stable protection

Reinforced concrete structure protection

Concrete structures such as bridges, parking lots, and offshore platforms typically contain reinforcing steel, which rusts over time.

Embedding MMO-coated titanium strip anodes into concrete provides cathodic protection for the internal reinforcing steel.

Applications include:

Bridges
Tunnels
Coastal buildings
Dock structures
Grounding systems and lightning protection

In grounding systems, stable conductivity is crucial.

MMO-coated titanium strip anodes feature:

Low resistance

Long-term stability

Strong environmental adaptability

Widely used in:

Power plants

Substations

Communication towers

Reinforced concrete structure protection

Concrete structures such as bridges, parking lots, and offshore platforms typically contain reinforcing steel, which rusts over time.

Grounding Systems and Lightning Protection

In grounding systems, stable conductivity is crucial.

MMO-coated titanium strip anodes possess the following characteristics:

Low resistance

Long-term stability

Strong environmental adaptability

Widely used in:

Power plants

Substations

Communication towers

Materials and Manufacturing Processes

High-purity titanium substrate

The substrate material is typically Grade 1 or Grade 2 titanium, characterized by:

Excellent corrosion resistance

High strength
Lightweight structure

This ensures that MMO-coated titanium strip anodes can withstand the corrosion of harsh environments such as soil, seawater, and concrete.

Advanced MMO Coating Technology

The coating is composed of a mixture of various metal oxides, such as:

Ruthenium oxide

Iridium oxide

Tantalum oxide

The coating is prepared using a thermal decomposition process, ensuring:

Strong adhesion

Uniform thickness

Long service life

Strict quality control

Each MMO-coated titanium strip anode undergoes the following tests:

Coating thickness test

Current density test

Adhesion test

Life simulation

This guarantees its stable performance in practical applications. Product Specifications and Customization

We offer a variety of MMO-coated titanium strip anodes:

Width: 6mm – 25mm

Thickness: 0.6mm – 1.2mm

Length: Customizable (roll available)

Coating Type: Optimized for soil, concrete, or seawater environments

Customization options include:

Pre-connected cables

Insulated or bare strips

Pre-assembled anode systems

Safety and Environmental Advantages

Using MMO-coated titanium strip anodes is not only highly efficient but also environmentally friendly.

No heavy metal pollution

Extremely low material consumption

Long service life, reducing waste

Compared to traditional sacrificial anodes, MMO systems are cleaner and more sustainable.

Why Choose Baoji Shenao Metal MMO-Coated Titanium Strip Anodes?

Strong Production Capacity

We possess advanced MMO-coated titanium strip anode production lines, including:

Precision coating equipment

Automated cutting and welding systems

High-temperature treatment furnaces

This ensures consistent product quality and fast delivery.

Strict Quality Management System

Our factory adheres to international quality standards, such as:

ISO Quality Management System

Fully traceable for every batch of products

Detailed inspection reports

Each MMO-coated titanium strip anode is tested before shipment.

Extensive Industry Experience

With years of experience in the field of electrochemical materials, we understand diverse application needs:

Soil resistivity variations

Concrete conductivity challenges

Marine corrosive environments

We provide customized solutions, not just products.

Patented Coating Technology

Our proprietary MMO coating formulation enhances:

Coating adhesion

Lifespan
Current efficiency

This makes our MMO-coated titanium strip anodes more reliable than standard products on the market.

Professional Technical Support

We not only sell MMO-coated titanium strip anodes but also provide comprehensive project support:

System design assistance

Installation guidance

After-sales technical service

Real-world application examples

In a recent oil storage project, our MMO-coated titanium strip anodes were used for bottom protection of the storage tank.

Results:

Uniform potential distribution

No corrosion detected after operation

Expected service life exceeds 25 years

This demonstrates the long-term reliability of our products.

How to Choose the Right MMO Coated Titanium Strip Anode?

When selecting an MMO coated titanium strip anode, consider the following factors:

Environment (soil, concrete, seawater)

Required current density

Installation method

Project lifespan

Our team can help you select the configuration based on your project requirements.

A Wise Investment for Long-Term Protection

MMO coated titanium strip anodes are a modern corrosion protection and grounding system solution.

With the following advantages:

Long service life

High efficiency

Low maintenance costs

Flexible installation

It is becoming the preferred choice across industries.

If you are looking for a reliable and cost-effective corrosion protection solution, MMO coated titanium strip anodes are the ideal choice.

Get a Quote Now

Looking for a trustworthy MMO coated titanium strip anode supplier?

Contact us now to receive:

Free technical consultation

Customized design solutions

Competitive pricing

Let us help you protect your assets with high-performance MMO-coated titanium strip anodizing solutions.
