titanium anode for nickel plating

The titanium anode used for nickel plating is an insoluble electrode made of high-purity titanium substrate, coated with catalytic layers such as iridium oxide (IrO), ruthenium oxide (RuO ₂), or platinum (Pt) on the surface. Realize efficient oxygen evolution reaction (OER) while maintaining dimensional stability.
Manufacturing process of nickel titanium anode
The performance of nickel plating on titanium anode largely depends on the precious metal coating technology. The production process ensures durability, catalytic activity, and stable electrochemical performance.
1: Preparation of titanium substrate
Use grade 1 or grade 2 titanium
Surface sandblasting to increase roughness and adhesion
Acid washing to remove oxide layer and impurities
2: Coating application technology
Thermal decomposition method of MMO coating
Multi layer coating enhances catalytic performance
Accurate control of coating thickness (usually 5-15 μ m)
3: Sintering and activation
High temperature sintering (400-500 ° C)
Formation of Stable Oxide Crystal Structure
Activation of Electrochemical Catalytic Performance
4: Quality inspection
Coating adhesion test
Accelerated Life Test
Electrochemical performance evaluation
Through these controlled processes, titanium anodes used for nickel plating have achieved excellent conductivity, durability, and efficiency.

Technical advantages of nickel plating on titanium anode
1: Dimensional stability
Unlike soluble nickel anodes, titanium anodes used for nickel plating do not dissolve during operation. Ensuring consistency in geometric shape and predictable current distribution.
2: Energy efficiency
Low oxygen release of overpotential reduces battery voltage, making nickel titanium plated anodes more energy-efficient in large-scale operations.
3: Environmental benefits
No production of heavy metal sludge
Reduce bath pollution
Reduce waste disposal costs
4: Customizable design
The titanium anode used for nickel plating can be made into various shapes:
Mesh anode
Flat anode
Tubular Anode
Basket anode

Application fields of nickel titanium anode
1: Automotive industry
Nickel plating is used for:
• Corrosion protection of components
Decorative chrome plated base layer
Wear resistant coating
Using titanium anode nickel plating can ensure uniform thickness and improve durability.
2: Electronic Manufacturing
In the field of electronics, accuracy is crucial. Titanium anode bracket for nickel plating:
PCB electroplating
Surface treatment of connectors
• Coating for semiconductor components
3: Aerospace industry
Aerospace components require:
• High reliability
• Corrosion resistance
• Lightweight coating
The titanium anode used for nickel plating meets these strict standards.
4: Mechanical and industrial equipment
Nickel plating has improved:
• Wear resistance
• Surface hardness
• Service life
The titanium anode used for nickel plating improves process stability and reduces downtime.

Product production process

Why Choose Us

At Baoji City ShenAo Metal Materials Co., Ltd, we focus on providing products that not only meet but exceed our customers’ expectations. Here’s why we’re the best choice for electroplating titanium electrodes:

1. Research and Innovation
   We have a dedicated R&D team that constantly innovates and improves our product offerings. By staying ahead of industry trends, we offer solutions that meet the unique challenges faced by our customers.

2. Excellent Reputation
   With 17 years of experience, our company has built a reputation for delivering high-quality products and reliable customer service. Our electroplating titanium electrodes have earned the trust of clients across various industries.

3. Striving for Excellence
   Our strict quality control processes ensure that every titanium electrode meets the highest standards. Whether for small-scale testing or large production runs, we deliver high-quality products on time.

4. Customized Product Services
   We understand that every project is unique. That’s why we offer customizable titanium electrodes to suit various specifications and technical requirements.

5. Timely Delivery and After-Sales Support
   We’re committed to providing excellent customer service. From fast response times to reliable after-sales support, we ensure that our customers’ needs are met efficiently.

6. OEM Services
   We offer OEM services to deliver tailor-made solutions to meet the specific demands of your project.

​

​

Baoji City shenAo Metal Materials Co., Ltd. was founded in 2008 and is located in the "China Titanium Valley" Shaanxi Baoji High tech Industrial Development Zone. It focuses on the research and production of non-ferrous metal composite materials, precious metal coated titanium anodes (DSA), and titanium cathode products. Based on mature bimetallic explosive welding technology and advanced active coating manufacturing process, relying on strong resources in the Chinese titanium valley industry and the processing and manufacturing capabilities for bidding for the Olympics, we accurately and timely meet customer needs and create value for customers; Leading the development of energy-saving and environmentally friendly metal composite materials products through technological innovation, and continuously improving to meet customers' demand for long-life titanium electrodes.

The company has established close partnerships with hundreds of non-ferrous metal equipment manufacturers and electrochemical application enterprises, and has been designated as a long-term high-quality supplier.

The company has established research and development, production, and marketing departments, with strict process technology quality and testing standards to ensure reliable products and fast delivery efficiency to global customers.

We provide a variety of customized services, mainly for the followingWe provide a variety of customized services, mainly for the following：

Waterjet Cutting
Laser Cutting
Welding
Plasma Welding
Polishing
Press
Hydraulic straightening machine
Bending
Drill Press

​​​​

​​​​

​​​​

​​​​

​​​​

​​​​

​​

​​​​

​​​​

​​​​​​​​​​​​​​​	​​​​​​​​​​​​​​​​	​​​​​​​​​​​​​​​​	​​​​​​​​​​​​​​​​
​​​​​​​​​​​​​​	​​​​​​​​​​​​​​	​​​​​​​​​​​​​​	​​​​​​​​​​​​​​

​​​​​​​​​​​​​​​​​

​​​​​​​​​​​​

​​​​

​​​​	​​​​	​​​​	​​​​	​​​​
​​​	​​​	​​​	​​	​​​

​​​​​​​​​​​​​​​

Frequently Asked Questions (FAQs)

• What are electroplating titanium electrodes made of?
  Electroplating titanium electrodes are made from high-purity titanium, typically Grade 2, with a platinum or ruthenium coating for enhanced performance.

• What is the lifespan of electroplating titanium electrodes?
  The lifespan depends on the application, but our electrodes are designed to last for years with proper maintenance.

• Can I customize the size of the electrodes?
  Yes, we offer customizable dimensions to meet your specific needs.

• How are these electrodes used in electroplating?
  Electroplating titanium electrodes are used to conduct electric current through the electrolyte, allowing the deposition of metals onto the workpiece.

• What industries use electroplating titanium electrodes?
  These electrodes are widely used in electroplating, water treatment, chemical manufacturing, energy production, and environmental protection.
